| 規 格 表 (平直型無固定環) ..................(適用軸公差 : h8 ; 適用輪轂孔公差 : H8 ; 適用表面粗度 : 12S 以下) |
 |
 |
|
(單位
:mm )|
規.....格
|
外型尺寸
|
傳達扭力
|
軸向力
|
軸側面壓
|
輪轂側面壓
|
安裝螺絲
|
質量
|
||||||||
|
d X D
|
t |
L
|
Lt
|
Mt
|
Pax
|
P
|
P'
|
數量
|
規格
|
懸緊扭力
|
kg
|
||||
|
內徑 X 外徑
|
N.m
|
kgf.m
|
kN
|
kgf
|
MPa
|
kgf/mm2
|
MPa
|
kgf/mm2
|
kgf.m
|
||||||
|
PL 005 X 018 RE-SS
|
8
|
13.5
|
16.5
|
6.73
|
0.69
|
3.27
|
334
|
191
|
19.5
|
53
|
5.4
|
3
|
M3X10
|
0.092
|
0.02
|
|
PL 006 X 019 RE-SS
|
8
|
13.5
|
16.5
|
9.23
|
0.94
|
3.27
|
334
|
159
|
16.3
|
50
|
5.1
|
3
|
M3X10
|
0.092
|
0.02
|
|
PL 008 X 021 RE-SS
|
8
|
13.5
|
16.5
|
18.5
|
1.9
|
4.36
|
445
|
159
|
16.3
|
61
|
6.2
|
4
|
M3X10
|
0.22
|
0.03
|
|
PL 010 X 026 RE-SS
|
10
|
16.5
|
20.5
|
41.0
|
4.2
|
7.75
|
791
|
181
|
18.5
|
70
|
7.1
|
4
|
M4X14
|
0.22
|
0.06
|
|
PL 011 X 027 RE-SS
|
10
|
17
|
21
|
45.1
|
4.6
|
7.75
|
791
|
165
|
16.8
|
67
|
6.9
|
4
|
M4X14
|
0.22
|
0.06
|
|
PL 012 X 028 RE-SS
|
10
|
17.5
|
21.5
|
61.6
|
6.3
|
9.69
|
989
|
189
|
19.3
|
81
|
8.3
|
5
|
M4X14
|
0.22
|
0.06
|
|
PL 014 X 030 RE-SS
|
11
|
18.5
|
22.5
|
86.2
|
8.8
|
11.7
|
1190
|
177
|
18.0
|
82
|
8.4
|
6
|
M4X14
|
0.22
|
0.08
|
|
PL 015 X 031 RE-SS
|
11
|
18.5
|
22.5
|
92.3
|
9.4
|
11.7
|
1190
|
165
|
16.8
|
80
|
8.1
|
6
|
M4X14
|
0.22
|
0.08
|
|
PL 016 X 032 RE-SS
|
11
|
18.5
|
22.5
|
98.5
|
10.1
|
11.7
|
1190
|
155
|
15.8
|
77
|
7.9
|
6
|
M4X14
|
0.22
|
0.08
|
|
PL 017 X 033 RE-SS
|
12
|
19.5
|
23.5
|
105
|
10.7
|
11.7
|
1190
|
133
|
13.6
|
69
|
7.0
|
6
|
M4X14
|
0.22
|
0.09
|
|
PL 018 X 034 RE-SS
|
12
|
20
|
24
|
111
|
11.3
|
11.7
|
1190
|
126
|
12.9
|
67
|
6.8
|
6
|
M4X14
|
0.22
|
0.10
|
|
PL 019 X 035 RE-SS
|
12
|
20
|
24
|
156
|
15.9
|
15.5
|
1580
|
159
|
16.2
|
86
|
8.8
|
8
|
M4X14
|
0.22
|
0.11
|
|
PL 020 X 039 RE-SS
|
13.5
|
23.5
|
28.5
|
244
|
24.9
|
23.0
|
2350
|
200
|
20.4
|
103
|
10.5
|
6
|
M5X20
|
0.54
|
0.15
|
|
PL 022 X 041 RE-SS
|
13.5
|
23.5
|
28.5
|
269
|
27.4
|
23.0
|
2350
|
182
|
18.6
|
98
|
10.0
|
6
|
M5X20
|
0.54
|
0.16
|
|
PL 024 X 043 RE-SS
|
15
|
26
|
31
|
391
|
39.9
|
30.8
|
3140
|
200
|
20.4
|
112
|
11.4
|
8
|
M5X20
|
0.54
|
0.19
|
|
PL 025 X 044 RE-SS
|
15
|
26
|
31
|
407
|
41.6
|
30.8
|
3140
|
192
|
19.6
|
109
|
11.1
|
8
|
M5X20
|
0.54
|
0.20
|
|
PL 028 X 049 RE-SS
|
16.5
|
28.5
|
33.5
|
570
|
58.6
|
38.4
|
3920
|
195
|
19.6
|
111
|
11.4
|
10
|
M5X20
|
0.54
|
0.27
|
|
PL 030 X 050 RE-SS
|
16.5
|
28.5
|
33.5
|
611
|
62.3
|
38.4
|
3920
|
182
|
18.6
|
109
|
11.1
|
10
|
M5X20
|
0.54
|
0.26
|
|
PL 032 X 052 RE-SS
|
17
|
29
|
34
|
652
|
66.5
|
38.4
|
3920
|
165
|
16.9
|
102
|
10.4
|
10
|
M5X20
|
0.54
|
0.28
|
|
PL 035 X 058 RE-SS
|
17
|
29
|
34
|
855
|
87.5
|
46.2
|
4710
|
182
|
18.5
|
110
|
11.2
|
12
|
M5X20
|
0.54
|
0.38
|
|
PL 038 X 060 RE-SS
|
18
|
31.5
|
37.5
|
1100
|
112
|
54.5
|
5560
|
187
|
19.0
|
118
|
12.1
|
10
|
M6X25
|
0.92
|
0.39
|
|
PL 040 X 063 RE-SS
|
18
|
31.5
|
37.5
|
1150
|
118
|
54.5
|
5560
|
177
|
18.1
|
113
|
11.5
|
10
|
M6X25
|
0.92
|
0.43
|
|
PL 042 X 066 RE-SS
|
19
|
34
|
40
|
1450
|
148
|
65.4
|
6670
|
192
|
19.6
|
122
|
12.5
|
12
|
M6X25
|
0.92
|
0.50
|
|
PL 045 X 068 RE-SS
|
19
|
34
|
40
|
1560
|
159
|
65.4
|
6670
|
179
|
18.3
|
119
|
12.1
|
12
|
M6X25
|
0.92
|
0.50
|
|
PL 048 X 072 RE-SS
|
19
|
34
|
40
|
1660
|
170
|
65.4
|
6670
|
168
|
17.1
|
112
|
11.4
|
12
|
M6X25
|
0.92
|
0.57
|
|
PL 050 X 075 RE-SS
|
19
|
35.5
|
41.5
|
2020
|
206
|
76.3
|
7790
|
188
|
19.2
|
125
|
12.8
|
14
|
M6X25
|
0.92
|
0.62
|
- 上表所示之傳達扭力值 ( M t ) 乃是當軸向力 ( Pax ) = 0 時之定義；而上表所示之軸向力 ( Pax ) 乃是當傳達扭力值 ( Mt ) = 0 時之定義。如果傳達扭力值 ( M t ) 與 軸向力( Pax ) 同時作用時，請計算合成負荷並與比較上表之傳達扭力值 ( M t )。
-
軸側與輪轂側面壓 P、P ' 是以平均值表示。這個值會因安裝螺絲拴緊時而有 -20 % ~ +20 % 的變動。
-
傳達扭力值 ( M t ) 與軸向力 ( Pax ) 是以面壓最低容許值時，計算之最小值。
 |
